TASK™ 7

Description

This low viscosity, fast-setting casting resin meets UL 94 V-O flame resistance standards.

TASK™ 7 is free from mercury, TDI, and MOCA. The mix ratio is 1A:1B by volume, with a Working time of 4.5 minutes and a demold time of 10 minutes at 23°C, depending on mass.

Once fully cured, the material is tough, durable, machinable, and paintable, offering superior physical and performance properties compared to other flame-rated urethanes.

Vibrant colors and effects can be achieved by adding SO-Strong™ color tints.

Technical Properties

Mix Ratio By Volume: 1A:1B
Mix Ratio By Weight: 104A:100B
Working time: 4.5 minutes
Cure Time: 10 minutes
Shore Hardness: 73 D
Specific Gravity: 1.2 g/cc
Specific Volume: 0.83 cm³/g
Color: Off-White
Elongation@Break: 15.1%
Tensile Strength: 23.4 MPa
Tensile Modulus: 1,038 MPa
Flexural Strength: 37.6 MPa
Flexural Modulus: 1,027 MPa
Compressive Strength: 35.4 MPa
Heat Deflection Temp: 55°C
Compressive Modulus: 397 MPa
Shrinkage: 0.0111 mm/mm
Mixed Viscosity: 200 mPa·s

Applications include flame-resistant prototypes, architectural models, model toys, theme park and stage elements, durable miniatures, and special-effect props.

TASK™ 7 is also suitable for potting and encapsulation applications.

Instructions

Storage and Handling

Store and use materials in a warm environment (23°C). The product has a limited shelf life and should be used promptly. All liquid urethanes are moisture sensitive. Use clean metal, glass, or plastic mixing tools and containers. Mix in a well-ventilated area. Wear safety glasses, long sleeves, and rubber gloves to minimize contamination risk.

Mixing Instructions

Pre-mix Parts A and B before dispensing. The proper mixing ratio is 1 Part A to 1 Part B by volume. Dispense equal amounts into a mixing container. If tinting or pigmenting, add color to Part B and mix thoroughly before adding Part A. Stir deliberately, scraping the sides and bottom of the container several times. Avoid splashing the low viscosity material out of the container.

Pouring and Curing

When casting into a rubber mold, pour the mixture at the lowest point of the mold. For encapsulating objects, do not pour directly over the object. Allow the mixture to level naturally. A uniform flow minimizes entrapped air. Best results are obtained using a pressure casting technique. After pouring, place the entire casting assembly in a pressure chamber and apply 4.2 kg/cm² air pressure for 1 hour.

Post Curing

Post curing is recommended for thin or low mass castings. Cure in a mold or support structure for 1 hour at room temperature, followed by 2 hours at 65 - 72°C. Allow the casting to cool to room temperature before handling.

Safety and Precautions

Use with at least room size ventilation or near a forced outlet air vent.

Do not inhale fumes. Fumes dissipate quickly with adequate ventilation.

Castings with significant mass may be hot and irritate skin immediately after curing. Allow castings to cool before handling.

Apply a release agent to facilitate demolding when casting into or over most surfaces. Use a release agent specifically for mold making, such as Universal™ Mold Release or Mann’s Ease Release™ 200. Apply a liberal coat of release agent on all surfaces that will contact the plastic. Ensure thorough coverage by brushing with a soft brush, followed by a light mist coating. Let the release agent dry for 30 minutes.

Specifications

Color	Off-White
Mixed Viscocity	200 cps
Cure Time	10 minutes
Pot Life	2.5 minutes
Flexural Strength	5,450 psi
Flexural Modulus	148,900 psi
Specific Volume	23.1 cu. in./lb.
Specific Gravity	1.2 g/cc
Mix Ratio By Weight	104A:100B
Shrinkage	0.0111 in. / in.
Mix Ratio By Volume	1A:1B
Tensile Strength	3,390 psi
Elongation At Break	15.1 %
Shore D Hardness	73
Heat Deflection Temp	131 °F
Compressive Strength	5,140 psi
Tensile Modulus	150,700 psi
Compressive Modulus	57,600 psi

Available in Polyurethane Resin

Product	Cure Time	Specific Gravity	Specific Volume	Tensile Strength	Tensile Modulus	Compressive Strength	Compressive Modulus	Flexural Strength	Shrinkage	Heat Deflection Temp	Elongation At Break	Flexural Modulus	Mixed Viscocity	Mix Ratio By Volume	Mix Ratio By Weight	Pot Life	Shore D Hardness	Color	Mixed Viscocity	Cure Time	Pot Life	Flexural Strength	Flexural Modulus	Specific Volume	Specific Gravity	Mix Ratio By Weight	Shrinkage	Mix Ratio By Volume	Tensile Strength	Elongation At Break	Shore D Hardness	Heat Deflection Temp	Compressive Strength	Tensile Modulus	Compressive Modulus	Handling Time	Handling Time	Heat Deflection With Post Cure	Heat Deflection With Post Cure	Shore A Hardness	Die C Tear Strength	Hundred Percent Modulus	Hundred Percent Modulus	Die C Tear Strength	Shore A Hardness
TASK™ 2	60 min.	1.12 g/cc	24.7 cu. in./lb.	6,650 psi	290,000 psi	8,300 psi	78,000 psi	9,500 psi	0.005 in. / in.	134 °F	6 %	288,000 psi	150 cps	1A:1B	115A:100B	7 min.	80	White	150 cps	60 min.	7 min.	9,500 psi	288,000 psi	24.7 cu. in./lb.	1.12 g/cc	115A:100B	0.005 in. / in.	1A:1B	6,650 psi	6 %	80	134 °F	8,300 psi	290,000 psi	78,000 psi	-	-	-	-	-	-	-	-	-	-
TASK™ 3	90 min.	1.12 g/cc	24.7 cu. in./lb.	6,650 psi	290,000 psi	8,300 psi	78,000 psi	9,500 psi	0.0025 in. / in.	134 °F	6 %	288,000 psi	150 cps	1A:1B	115A:100B	20 min.	80	White	150 cps	90 min.	20 min.	9,500 psi	288,000 psi	24.7 cu. in./lb.	1.12 g/cc	115A:100B	0.0025 in. / in.	1A:1B	6,650 psi	6 %	80	134 °F	8,300 psi	290,000 psi	78,000 psi	-	-	-	-	-	-	-	-	-	-
TASK™ 4	16 h.	1.167 g/cc	23.9 cu. in./lb.	6,500 psi	130,000 psi	7,400 psi	75,000 psi	9,000 psi	0.0035 in. / in.	110 °F	4 %	204,000 psi	250 cps	-	100A:100B	20 min.	83	Ivory	250 cps	16 h.	20 min.	9,000 psi	204,000 psi	23.9 cu. in./lb.	1.167 g/cc	100A:100B	0.0035 in. / in.	-	6,500 psi	4 %	83	110 °F	7,400 psi	130,000 psi	75,000 psi	-	-	-	-	-	-	-	-	-	-
TASK™ 5	24 h.	1.1 g/cc	25.2 cu. in./lb.	4,530 psi	200,000 psi	6,700 psi	83,000 psi	6,480 psi	0.007 in. / in.	145 °F	5 %	216,000 psi	600 cps	1A:1B	1A:1B	3 min.	77	Tan	600 cps	24 h.	3 min.	6,480 psi	216,000 psi	25.2 cu. in./lb.	1.1 g/cc	1A:1B	0.007 in. / in.	1A:1B	4,530 psi	5 %	77	145 °F	6,700 psi	200,000 psi	83,000 psi	15 min.	15 min.	-	-	-	-	-	-	-	-
TASK™ 6	24 h.	1.07 g/cc	25.9 cu. in./lb.	5,200 psi	146,000 psi	5,570 psi	65,000 psi	6,200 psi	0.0031 in. / in.	162 °F	4 %	182,500 psi	800 cps	1A:1B	1A:1B	7 min.	75	Tan	800 cps	24 h.	7 min.	6,200 psi	182,500 psi	25.9 cu. in./lb.	1.07 g/cc	1A:1B	0.0031 in. / in.	1A:1B	5,200 psi	4 %	75	162 °F	5,570 psi	146,000 psi	65,000 psi	75 min.	75 min.	-	-	-	-	-	-	-	-
TASK™ 7	10 min.	1.2 g/cc	23.1 cu. in./lb.	3,390 psi	150,700 psi	5,140 psi	57,600 psi	5,450 psi	0.0111 in. / in.	131 °F	15.1 %	148,900 psi	200 cps	1A:1B	104A:100B	2.5 min.	73	Off-White	200 cps	10 min.	2.5 min.	5,450 psi	148,900 psi	23.1 cu. in./lb.	1.2 g/cc	104A:100B	0.0111 in. / in.	1A:1B	3,390 psi	15.1 %	73	131 °F	5,140 psi	150,700 psi	57,600 psi	-	-	-	-	-	-	-	-	-	-
TASK™ 8	15 min.	1.09 g/cc	25.4 cu. in./lb.	5,840 psi	246,000 psi	8,760 psi	77,400 psi	8,280 psi	0.01 in. / in.	194 °F	4 %	271,000 psi	100 cps	1A:1B	120A:100B	2.5 min.	80	Off-White	100 cps	15 min.	2.5 min.	8,280 psi	271,000 psi	25.4 cu. in./lb.	1.09 g/cc	120A:100B	0.01 in. / in.	1A:1B	5,840 psi	4 %	80	194 °F	8,760 psi	246,000 psi	77,400 psi	-	-	263 °F	263 °F	-	-	-	-	-	-
TASK™ 11	16 h.	1.12 g/cc	24.7 cu. in./lb.	2,500 psi	-	-	-	-	0.0024 in. / in.	-	100 %	-	2,000 cps	-	100A:100B	20 min.	60	Translucent White	2,000 cps	16 h.	20 min.	-	-	24.7 cu. in./lb.	1.12 g/cc	100A:100B	0.0024 in. / in.	-	2,500 psi	100 %	60	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TASK™ 12	16 h.	1.08 g/cc	26 cu. in./lb.	2,700 psi	-	-	-	-	0.001 in. / in.	-	300 %	-	2,400 cps	-	100A:44B	20 min.	60	Clear Amber	2,400 cps	16 h.	20 min.	-	-	26 cu. in./lb.	1.08 g/cc	100A:44B	0.001 in. / in.	-	2,700 psi	300 %	60	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TASK™ 13	20 min.	1.15 g/cc	24.1 cu. in./lb.	1,800 psi	-	-	-	-	0.005 in. / in.	-	125 %	-	800 cps	-	100A:120B	3 min.	50	Black	800 cps	20 min.	3 min.	-	-	24.1 cu. in./lb.	1.15 g/cc	100A:120B	0.005 in. / in.	-	1,800 psi	125 %	50	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TASK™ 14	45 min.	1.15 g/cc	24.1 cu. in./lb.	1,800 psi	-	-	-	-	0.0035 in. / in.	-	125 %	-	800 cps	-	100A:120B	10 min.	50	Black	800 cps	45 min.	10 min.	-	-	24.1 cu. in./lb.	1.15 g/cc	100A:120B	0.0035 in. / in.	-	1,800 psi	125 %	50	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TASK™ 15	1 h.	1.12 g/cc	24.7 cu. in./lb.	2,720 psi	126,000 psi	5,450 psi	60,000 psi	5,450 psi	0.0042 in. / in.	117 °F	20 %	170,000 psi	600 cps	-	75A:100B	6 min.	75	Opaque White	600 cps	1 h.	6 min.	5,450 psi	170,000 psi	24.7 cu. in./lb.	1.12 g/cc	75A:100B	0.0042 in. / in.	-	2,720 psi	20 %	75	117 °F	5,450 psi	126,000 psi	60,000 psi	-	-	-	-	-	-	-	-	-	-
TASK™ 16	24 h.	1.08 g/cc	25.64 cu. in./lb.	2,264 psi	-	-	-	-	0.0025 in. / in.	-	233 %	-	1,400 cps	-	1A:2B	6 min.	30	Light Yellow	1,400 cps	24 h.	6 min.	-	-	25.64 cu. in./lb.	1.08 g/cc	1A:2B	0.0025 in. / in.	-	2,264 psi	233 %	30	-	-	-	-	90 min.	90 min.	-	-	80	197 pli	855 psi	855 psi	197 pli	80
TASK™ 18	16 h.	1.57 g/cc	17.6 cu. in./lb.	3,250 psi	514,000 psi	8,420 psi	97,300 psi	10,700 psi	0.0006 in. / in.	149 °F	1 %	86,000 psi	4,400 cps	-	26A:100B	20 min.	88	Metal Gray	4,400 cps	16 h.	20 min.	10,700 psi	86,000 psi	17.6 cu. in./lb.	1.57 g/cc	26A:100B	0.0006 in. / in.	-	3,250 psi	1 %	88	149 °F	8,420 psi	514,000 psi	97,300 psi	-	-	-	-	-	-	-	-	-	-
TASK™ 21	1 h.	1.07 g/cc	25.9 cu. in./lb.	5,500 psi	270,000 psi	7,100 psi	78,500 psi	7,100 psi	0.0058 in. / in.	144 °F	7.5 %	250,000 psi	500 cps	2A:1B	2A:1B	6 min.	75	White	500 cps	1 h.	6 min.	7,100 psi	250,000 psi	25.9 cu. in./lb.	1.07 g/cc	2A:1B	0.0058 in. / in.	2A:1B	5,500 psi	7.5 %	75	144 °F	7,100 psi	270,000 psi	78,500 psi	-	-	-	-	-	-	-	-	-	-
